Name: 400G QSFP-DD ZR Coherent Transceiver 0-75℃
Brand: Shenzhen HiLink Technology Co.,Ltd.
SKU: 400G-QSFPDD-ZR
Price: 130.00 USD
Availability: InStock

Evde > Ürünler > optik alıcı modülü >

400G QSFP-DD ZR Coherent Transceiver 0-75℃

400G QSFP-DD ZR transceiver module

coherent optical transceiver 0-75℃

QSFP-DD transceiver with extended temperature range

Menşe yeri:

Guangdong, Çin

Marka adı:

Hilink

Sertifika:

CE Rohs

Model numarası:

400G-QSFPDD-ZR

Bizimle İletişim

Bir İndirim İste

400G QSFP-DD ZR Coherent Transceiver 0-75℃

Ürün Ayrıntıları

Ürün adı:

400G-QSFPDD-ZR

Veri oranı:

400g

Çalışma sıcaklığı:

0 ila 75 ℃

Ödeme ve Nakliye Şartları

Min sipariş miktarı

1 parça

Fiyat

Send Inquiry know latest price

Ambalaj bilgileri

Plastik kutu+karton

Teslim süresi

5-8 İş Günü

Ödeme koşulları

T/T, Western Union, Alipay, PayPal/Wechat/Ticaret Güvencesi

Yetenek temini

Haftada 2000 Parça

İlişkili Ürünler

100G QSFP28 SR BiDi OM4 MMF 100m LC Optik Alıcı

En İyi Fiyatı Alın

Video

OSFP800 800G 2xSR4 Optik Alıcı-Verici 12V Fiber Optik Alıcı-Verici MPO Konnektör

En İyi Fiyatı Alın

100G QSFP28 SRBD 100m Bi-Di Duplex LC Hot Pluggable 850/900nm VCSEL PAM4 2x50G Multimode

En İyi Fiyatı Alın

25G SFP28 BIDI Optik Modülü Fiber Bağlantısı LC 0 ila 70C 3km/10km/40km/60km

En İyi Fiyatı Alın

Bizimle İletişim

+86 15917174650

sales05@hilinktech.com

86-755-8317-6243

Şimdi iletişime geçin

Ürün Tanımı

400G QSFP-DD ZR Coherent Transceiver 0-75℃

Product Overview

The 400G QSFP-DD ZR Transceiver is a high performance, cost effective module for optical data communication applications to 400G. The 400G QSFP-DD ZR is designed to 400G 120Km DCI DWDM applications without inline chromatic dispersion compensation.

Features

QSFP-DD MSA compliant type 2B package
Up to 120Km transmission distance
Client signal 400GbE or 4x100GbE
Line Modulation format 400G DP-16QAM
C-band tunable, supports 100/75GHz grid spacing, support 0.1GHz fine tuning
TX power -13dBm~-9dBm tunable
Support ingress LF hold-off time configure
Support hitless firmware upgrade
Compact size (18.35 mm × 93.26 mm × 8.50 mm)
Duplex LC Receptacle
Operating case temperature: 0℃ to 75°C
Maximum power consumption 18W (400GbE)
Single 3.3 V power supply
RoHS 2 compliant

Applications

Edge DCI 400GBASE-ZR application
30~40Km unamplified 400GbE P2P link
Up to 120Km P2P link with amplification

Product Images

Quality Assurance

Warranty & Quality Commitment:
All advertised optical transceivers are brand new with new components. We never use old or refurbished materials. Each unit undergoes functional and aging tests before shipment.

3-Year Warranty:
We provide a 3-year warranty for all optical transceivers from the date of shipment. OEM/ODM orders are available upon request.
